TECHSPEC® 부품은 에드몬드 옵틱스가 설계, 사양 지정 및 제조하는 제품입니다. 더 알아보기

Broadband VIS 2X - 8X Research-Grade Variable Beam Expander

Broadband VIS 2X - 8X, #87-569

Broadband VIS 2X - 8X, #87-569

재고 #87-569
KRW 1,642,600
×
수량 1-4
KRW 1,642,600
수량 5
KRW 1,368,600
수량 가격
견적 요청


Design Wavelength DWL (nm):
Broadband
Expansion Power:
2X - 8X
Coating:
BBAR (425-700nm)
Style:
Variable Magnification
Wavelength Range (nm):
425 - 700
Entrance Aperture (mm):
15
Exit Aperture (mm):
30
Transmitted Wavefront, P-V:
<λ/4 @ 633nm for Input Beam ≤4mm (2X-6X)
<λ/4 @ 633nm for Input Beam ≤2mm (>6X)
Mounting Threads:
Input: Male C-Thread (1" x 32 TPI)
Output: Male T-Thread (M42 x 0.75)
Substrate:
Housing Diameter (mm):
51
Length (mm):
169.0
Angle of Incidence (°):
0 ±0.06
Transmission (%):
>95 @ DWL
Coating Specification:
Ravg <1.0% @ 425 - 700nm
Type:
Beam Expander
Divergence Adjustment:
Non-Rotating Optics
Weight (g):
501

Regulatory Compliance

제품명

For optimal performance, center the laser beam to the entrance lens and ensure that the beam is parallel to the beam expander’s optical axis.

기술 정보

2X-8X Research-Grade Variable Beam Expanders - Specifications
Design Wavelength Stock No. Fixed Overall Length A (mm) Mounting Length E (mm) Rotating Numeric Ring Length F (mm) Rotating Alpha Ring Length G (mm)
355nm #87-566 169.7 35.9 90.7 19.4
532nm #87-567 169.3 31.5 70.4 43.7
Broadband VIS (633nm) #87-569 169.3 31.5 70.4 43.7
Broadband NIR (785nm) #87-570 169.3 31.5 70.4 43.7
1064nm #87-568 169.3 31.5 70.4 43.7
