Name: 8.5mm f/1.8, 75mm-∞ Primary WD, HRi Series Fixed Focal Length Lens
Brand: TECHSPEC
SKU: 36-747
Price: KRW 849,100

Iris Option:

Fixed

Length (mm):

44.57

Horizontal Field of View, 1/2" Sensor:

71.9mm - 42.2°

Horizontal Field of View, 2/3" Sensor:

101.4mm - 56.8°

Filter Thread:

M58 x 0.75 with adapter #87-425

Maximum Diameter (mm):

Weight (g):

Horizontal Field of View, 1/3" Sensor:

53.2mm - 32.0°

Maximum Rear Protrusion (mm):

1.31

Maximum Image Circle (mm):

Numerical Aperture NA, Object Side:

0.0249

Horizontal Field of View @ Max Sensor Format:

101.4mm - 56.8°

Number of Elements (Groups):

9 (8)

Horizontal Field of View, 1/1.8" Sensor:

81.5mm - 47.2°

Front Thread:

M40 x 0.5 (Male)

Horizontal Field of View, 1/2.5" Sensor:

64.8mm - 38.4°

Type:

Fixed Focal Length Lens

Focal Length FL (mm):

8.50

Primary Magnification PMAG:

0.092

Maximum Sensor Format:

2/3"

Working Distance (mm):

75 - ∞

Mount:

C-Mount

Style:

VIS

Aperture (f/#):

f/1.8

Coating:

425 - 675nm BBAR

Coating Specification:

425 - 675nm BBAR

Entrance Pupil Position (mm):

18.85

Horizontal Field of View, 1/4" Sensor:

39.6mm - 24.1°

Object Space Principal Plane (mm):

25.03

Image Space Principal Plane (mm):

4.70

Field of View at Max Sensor Format:

Horizontal: 101.4mm - 56.8°
Vertical: 74.2mm - 43.5°
Diagonal: 130.5mm - 68.9°

Maximum Distortion (%):

-5.6

Exit Pupil Position (mm):

-17.93

Optimized Working Distance (mm):

75 - ∞

Regulatory Compliance

RoHS:

규격준수

Certificate of Conformance:

보기

제품군의 상세 설명

2/3", C-마운트 렌즈
최대 900만 화소, 1.85µm 픽셀 크기의 센서
당사 HR Series Lens의 Instrumentation (HRi) 버전으로서 간소화된 기계적 설계 및 고정 조리개가 특징
초점 거리: 8.5 - 12mm
강건설계(Cr) 버전 보유

TECHSPEC® 2/3” HPi Series Fixed Focal Length Lenses는 당사 2/3” HP Series Lenses의 간소화된 버전입니다. 이 렌즈는 최적화된 다양한 작동 거리 범위를 수용할 수 있도록 각각의 초점 거리에 적용할 수 있는 여러 가지 옵션을 가지고 있습니다. 대량의 이미징 용도로 설계된 HPi series lenses는 간소화된 포커싱 메커니즘과 고정형 조리개를 특징으로 합니다. TECHSPEC 2/3” HPi Series Fixed Focal Length Lenses는 다양한 f/# 옵션을 이용할 수 있어 소형 크기, 적은 비용, 잠금식 포커스 이미징 솔루션을 필요로 하는 용도에 사용하기 적합합니다. OEM 수량 및 견적은 전화 문의.

에드몬드 옵틱스는 고성능으로 설계된 광학 제품군(2/3” HP 시리즈)를 제조함에 동시에 특정 용도를 대상으로 한 3가지 맞춤형 광기계 솔루션을 개발하였습니다. 이 렌즈의 하위 제품군 또한 고객의 어플리케이션 요건을 충족할 수 있도록 2/3” HP Series Lenses와 똑같은 옵틱을 사용함에 따라 다양한 광기계 솔루션에 적합한 동일한 광학적 성능을 제공합니다.

2/3” HP Series: locking cam focus 및 아이리스 조절 제공. 이 시리즈는 관련 제품군의 광학 설계 중에서도 조절이 가장 용이한 버전이며, 전형적인 고품질의 머신 비전 렌즈입니다.
2/3” HPi Series: 콤팩트 하우징에 고정 조리개를 특징으로 하는 간소화된 메커니즘. 산업 등급의 강건설계가 적용되어 저비용의 소형 크기 및 잠금 포커스 제공.
2/3” HPr Series: 모든 광학 요소를 제자리에 고정 처리하는 안정성 등급의 강건설계가 적용되고 잠금식 C-clamp focus ring이 있어 픽셀의 이동이 감소하고 초점의 안정성이 향상됨.

#36-747, 8.5mm f/1.8, 75mm-∞ Primary WD, HRi Series Fixed Focal Length Lens, Distortion Plot

#36-747, 8.5mm f/1.8, 75mm-∞ Primary WD, HRi Series Fixed Focal Length Lens, Relative Illumination Plot

#36-747, 8.5mm f/1.8, 75mm-∞ Primary WD, HRi Series Fixed Focal Length Lens, Working Distance versus Field of View Plot

#36-747, 8.5mm f/1.8, 75mm-∞ Primary WD, HRi Series Fixed Focal Length Lens, Modulated Transfer Function (MTF) Plot, 200mm Working Distance, f1.8

#36-747, 8.5mm f/1.8, 75mm-∞ Primary WD, HRi Series Fixed Focal Length Lens, Depth of Field Plot, 200mm Working Distance, f1.8

#36-747, 8.5mm f/1.8, 75mm-∞ Primary WD, HRi Series Fixed Focal Length Lens, Modulated Transfer Function (MTF) Plot, 500mm Working Distance, f1.8

#36-747, 8.5mm f/1.8, 75mm-∞ Primary WD, HRi Series Fixed Focal Length Lens, Depth of Field Plot, 500mm Working Distance, f1.8
