Entrance Pupil Position (mm):
Measured from the first lens surface on the object side. Positive values indicate direction toward the image side; negative values indicate direction toward the object side.
11.74
Object Space Principal Plane (mm):
Measured from the first lens surface on the object side. Positive values indicate direction toward the image side; negative values indicate direction toward the object side.
17.40
Image Space Principal Plane (mm):
Measured from the last lens surface on the image side. Positive values indicate direction toward the image side; negative values indicate direction toward the object side.
1.93
Maximum Distortion (%):
-1.48
Exit Pupil Position (mm):
Measured from the last lens surface on the image side. Positive values indicate direction toward the image side; negative values indicate direction toward the object side.
