60X Objective, S Plan Fluor ELWD

Name: 60X Objective, S Plan Fluor ELWD
Brand: Nikon
SKU: 75-375
Price: KRW 8,890,008 KRW

Nikon 상세 정보 보기

재고 번호 #75-375 신제품 1개 보유

- +

KRW 8,890,008

가격(부가세 별도/Tax excluded)
수량 1+	KRW 8,890,008 개당
더 필요하신가요?	견적 요청

+ 저장 목록에 추가하기
Create an account or log in to access saved list

제품 비교하기

제품 정보 다운로드

제품사양

General

Model Number:

MRH08630

Compatible Tube Lens Focal Length (mm):

Focal Length: 200mm

Type:

Microscope Objective

Style:

Infinity Corrected

Manufacturer:

Nikon

Physical & Mechanical Properties

Field of View (mm):

0.37

Length excluding Threads (mm):

57.41

Maximum Diameter (mm):

31.5

Weight (g):

165

Optical Properties

Compatible Cover Glass Thickness (mm):

0.1-1.3

Horizontal Field of View, 1/2" Sensor:

0.107

Horizontal Field of View, 2/3" Sensor:

0.147

Magnification:

60X

Numerical Aperture NA:

0.7

Working Distance (mm):

1.8-2.6

Field Number (mm):

Parfocal Length (mm):

60.41

Immersion Liquid:

N/A

Sensor

Maximum Sensor Format:

2/3"

Threading & Mounting

Mounting Threads:

M25 x 0.75

Regulatory Compliance

Certificate of Conformance:

보기

제품설명

Extra-Long Working Distance (ELWD)
Broad Spectral Transmittance
Versatility in Observation Modes

Nikon CFI S Plan Fluor ELWD Objectives are designed with an extra-long working distance to allow for high-resolution imaging of large samples and culture vessels of varying thicknesses. With broad spectral transmittance, from near-ultraviolet to near-infrared wavelengths, these objectives enable versatile imaging across multiple advanced microscopy techniques. These objectives allow for greater flexibility and protect delicate specimens during observations by not requiring immersion media. Nikon CFI S Plan Fluor ELWD Objectives are available in a variety of magnifications and support common observation modes, including brightfield, darkfield, DIC, phase contrast, and polarizing microscopy. These objectives are ideal for general fluorescence, brightfield, calcium imaging, and DIC applications.
